Detroit Speed DSE Independent Rear Suspension 1963-79 Corvette Base Shocks 17 Spline Axles 600 HP 041740

Detroit Speed DSE Independent Rear Suspension 1963-79 Corvette Base Shocks 17 Spline Axles 600 HP 041740
Detroit Speed DSE Independent Rear Suspension 1963-79 Corvette Base Shocks 17 Spline Axles 600 HP 041740
$16,736.99 kt
NEWOUT OF STOCK
Model: 3956596
Select a Vehicle or refer to the Vehicle Fitment Tab below to verify that this part fits your vehicle.
OVERSIZE 2

The Decalink Independent Rear Suspension features no compromises and exclusive Detroit Speed suspension geometry for superior handling and ride quality. The IRS utilizes modern CV axle shafts and hub bearings, keeping suspension loads from being transmitted through the axle shafts.

The Decalink IRS works with an original 17-spline differential assembly with upgrades to 30-spline or a Hammerhead 12-bolt differential. No body modifications are required on 1968-79 models while the suspension is offset inboard for additional tire clearance. All suspension link lengths are adjustable and the kit has adjustments for rear anti-squat geometry and roll center height. The suspension points are hard mounted to eliminate stock rubber mounted suspension deflection.

It comes with forged in the USA Detroit Speed aluminum uprights and a two-piece cast aluminum/steel cradle assembly which eases differential housing removal. DSE/JRi Detroit Tuned Coilover shocks/springs allow spring rate tuning and ride height adjustments. The kit includes a rear anti-roll bar and uses OEM cross-axis pivot bushings at all pivot points. The kit also includes Torrington bearings and a spanner tool for easy spring height adjustments.
Details:

  • Detroit Speed, Inc. Decalink Independent Rear Suspension Kit - 17 Spline Axles - 600HP - Base Shocks
  • Utilizes Modern CV Axle Shafts and Hub Bearings
  • 17 Spline Differential Assembly
  • Aluminum Uprights and Two-Piece Cast Aluminum/Steel Cradle Assembly
  • Heavy Duty Steel and Aluminum Construction Throughout
  • Black Powdercoat Finish On Steel Components
  • Includes Torrington Bearings and Spanner Tool
  • Cutting and Welding Required
  • Spring Rate: 550 Lbs/Inch
  • Spring Free Length: 8 Inches
  • Sold As A Kit
  • SKU: 041740

Fits Vehicles:

  • 1963-1979 Chevrolet Corvette

Base Shock:

  • The DSE/JRI Detroit Tuned base shock is a pure blood pedigree racing shock in its most efficient form as a non-adjustable unit. Although non-adjustable, it shares all the increased dynamic responses of all the JRI adjustable models while providing excellent ride quality on the street.

Note:

  • Torrington Bearings come with all shock packages included/purchased with the Decalink Rear Suspension
  • Corvette frame and differential not included with Decalink rear suspension

Wheel Fitment - Tire Recommendation: (Stock Body)

  • 17 x 8 Inch w/ 4 Inch Backspacing - 245/45R17
  • 17 x 9 Inch w/ 4.5 Inch Backspacing - 275/40R17 (Maximum Width Recommended)
  • 18 x 8 Inch w/ 4 Inch Backspacing - 245/40R18
  • 18 x 9 Inch w/ 4.5 Inch Backspacing - 275/35R18
  • 18 x 10 Inch w/ 5.5 Inch Backspacing - 295/35R18 (Maximum Width Recommended)

Wheel Fitment - Tire Recommendation: (Flared Body)

  • 18 x 11.5 Inch w/ 5.5 Inch Backspacing - 315/30R18
  • 18 x 12.5 Inch w/ 5.5 Inch Backspacing - 335/30R18 (Maximum Width Recommended)

Decalink Specifications:

  • Total Suspension Travel: 6 Inches
  • Ride Height: 3 Inches Plus/Minus 1 Inch (Measured from bottom edge of upper cradle frame mount bracket to center of hub)
  • Static Camber: -0.3 Degrees Plus/Minus 0.2 Degrees
  • Static Toe: 0 Degrees Plus/Minus 0.1 Degrees
  • Total Bump Steer: 0.027 Inch (20 Inch Toe Span)

About Detroit Speed

Detroit Speed puts a significant amount of effort into developing long-lasting, dependable products that are formulated to exceed late-model performance expectations. Our systems are designed by exceptionally qualified engineers and built by fabricators dedicated to making the best systems they possibly can. Our parts are made using state-of-the-art manufacturing technologies–CNC machining, forging, hydroforming, and more–to bring your classic muscle car to the 21st century.

Months of testing, revising, and polishing stand behind every product we make available to the public, and our test cars prove the point. Each of our development mules receive thousands of hard miles attending car shows, completing road trips, crushing autocross paddocks, and storming track days in the process. The pursuit of perfection has always been our primary goal, and it always will be. Because of this, we can confidently say our systems are the best, most comprehensive solutions to any and all your muscle car problems.

Videos:

Vehicle Fitment:

The Vehicle Fitment Guide is to be used as a general reference. The data has been provided by our suppliers and manufacturers and may contain errors or incorrect data. Always refer to a professional to verify correct fitment for your vehicle.
Make Model Submodel Years
Chevrolet Corvette Indianapolis 500 Pace Car 1978
Chevrolet Corvette Silver Anniversary Edition 1978
Chevrolet Corvette Stingray 1975 - 1976
Chevrolet Corvette 1963 - 1979

Specifications:

Adjust Type Base
Axle Spline 17 Spline
Chassis Codes GM C3 Corvette, GM C2 Corvette
Color Black/Silver
Finish Bare/Powdercoat
Location Rear
Manufacturer Warranty 2-Year Limited Defects and Workmanship
Material Steel/Aluminum
Motor Horsepower 600HP
Ride Height 3 Inches Plus/Minus 1 Degree
Series Decalink
Spring Free Length 8.0 Inch
Spring Rate 550 Lbs
Static Camber 0.3 Degrees Plus/Minus 0.2 Degrees
Static Toe 0 Degrees Plus/Minus 0.1 Degree
Thread M12 x 1.5
Total Bumpsteer 0.27 Inches (20 Inch Toe Span)
Travel Length 6.0 Inch
Vehicle Type Car
Wheel Bolt Pattern In. 5 x 4.75 Inch
Wheel Fitment 17 x 8 Inch w/ 4 Inch Backspacing - 245/45R17, 17 x 9 Inch w/ 4.5 Inch Backspacing - 275/40R17 (Maximum Width Recommended), 18 x 10 Inch w/ 5.5 Inch Backspacing - 295/35R18 (Maximum Width Recommended) For Stock Body, 18 x 11.5 Inch w/ 5.5 Inch Backspacing - 315/30R18, 18 x 12.5 Inch w/ 5.5 Inch Backspacing - 335/30R18 (Maximum Width Recommended) For Flared Body, 18 x 8 Inch w/ 4 Inch Backspacing - 245/40R18, 18 x 9 Inch w/ 4.5 Inch Backspacing - 275/35R18
